PL Mãe Gigabyte B550 AORUS ELITE (AM4/DDR4/HDMI/ATX)

Processador:

Suporta AMD Socket AM4, suporte para 3ª Geração AMD Ryzen™ / Nova Geração AMD Ryzen™ com gráficos Radeon™ Graphics

Chipset: AMD B550

Memória RAM:

Suporta 4 x DDR4 DIMM sockets até 128 GB

3ª Geração AMD Ryzen™

Suporta os seguintes módulos de memória DDR4 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules

Nova Geração AMD Ryzen™ com gráficos Radeon™ Graphics

Suporta os seguintes módulos de memória DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) /3200/2933/2667/2400/2133 MHz memory modules

Arquitetura de memória Dual Channel

Suporta módulos de memória ECC Un-buffered DIMM 1Rx8/2Rx8

Suporta módulos de memória non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16

Suporta módulos de memória Extreme Memory Profile (XMP)

Slots de Expansão:

1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:

3ª Geração AMD Ryzen™ suporta PCIe 4.0 x16 mode

Nova Geração AMD Ryzen™ com gráficos Radeon™ Graphics suporta PCIe 3.0 x16 mode

1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:

1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:

Supporting PCIe 3.0 x2 mode

1 x PCI Express x16 slot (PCIEX1_2), integrated in the Chipset:

Supporting PCIe 3.0 x1 mode

1 x PCI Express x1 slot (PCIEX1_1), integrated in the Chipset:

Supporting PCIe 3.0 x1 mode

Armazenamento:

1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:

3rd Generation AMD Ryzen™ processors support SATA and PCIe 4.0 x4/x2 SSDs

New Generation AMD Ryzen™ with Radeon™ Graphics processors support SATA and PCIe 3.0 x4/x2 SSDs

1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:

Supporting SATA and PCIe 3.0 x4/x2 SSDs

4 x SATA 6Gb/s connectors, integrated in the Chipset:

Suporte para RAID 0, RAID 1, RAID 5, and RAID 10

LAN:

Realtek® 2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

Áudio:

Realtek® ALC1220-VB codec

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

Portas USB:

CPU:

2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

2 x USB 3.2 Gen 1 ports on the back panel

Chipset:

2 x USB 3.2 Gen 1 ports on the back panel

2 x USB 3.2 Gen 1 ports available through the internal USB header

2 x USB 2.0/1.1 ports on the back panel

Chipset+USB 2.0 Hub:

4 x USB 2.0/1.1 ports available through the internal USB headers

Conectores I/O:

1 x 24-pin ATX main power

1 x 8-pin ATX 12V power

2 x M.2 Socket 3

4 x SATA 6Gb/s

1 x CPU fan header

1 x water cooling CPU fan header

3 x system fan headers

1 x CPU cooler LED strip/RGB LED strip header

2 x addressable LED strip headers

2 x RGB LED strip headers

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

2 x USB 2.0/1.1 headers

1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

1 x Clear CMOS jumper

Portas Painel Traseiro:

1 x DisplayPort

1 x HDMI

2 x USB 3.2 Gen 2 Type-A (red)

4 x USB 3.2 Gen 1

2 x USB 2.0/1.1

1 x Q-Flash Plus button

1 x RJ-45

1 x optical S/PDIF Out connector

5 x audio jacks

Dimensões:Formato ATX , 30.5cm x 24.4cm
